Christie CP2315-RGB


Part Number: 163-010102-01
Image Christie CP2315-RGB
Customer review
Offer Ads
Discover other popular projectors on Amazon!
Model Overview Equipped with DLP technology, the Christie CP2315-RGB offers 13500 ANSI lumens, a contrast of 3000:1 and is designed as a versatile projector.
Thanks to the interchangeable lens system, the device can be equipped with optional lenses to react flexibly to different room sizes. Exact values for specific rooms are provided by the Projection Calculator.
Regarding projection size, the value of 13500 ANSI lumens allows for an image width of up to 1012 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 675 cm.
For media input, video signals up to 1080P are supported. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket.
This model dates back to 2018 and is no longer part of Christie's current product range.
Display Type       3 x 0,96" DMD Chip
      HD2K 4/3 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
13500
Screen
4500 Lux (200 cm Screen width)
Contrast 3000:1 3000:1
Black Level 4,5000 min. Lumen 1,502 min. Lumen
Offset -
Resolution HD2K 2048 x 1080
2.211.840 Pixel
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p
Application Event | Very large screen width and rooms with plenty of light and shaded daylight.
Light Source -
Light Life -
Operating Costs -
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux: 4500 Lux
Contrast: 3000:1
Candela pro m²: 1432 cd/m²
Foot-Lamberts: 418 fL

Screen width:cm
          Room:
Focus Powered
Zoom Powered
Objective
Throw Ratio optional
Audio -
Connections 2 x HDMI in v1.4a
3D Sync Connector
16-channel AES (w/ Christie IMB-S3 via RJ45 x2)
2K120 / 4K30 fps (w/Christie IMB-S3)
Ceiling Mounting Yes, is possible.
Power -
Size WxHxD 1083 x 337 x 635 mm (42,6"x13,3"x25") 231,76 L/dm³
Operating Noise -

Weight 79,00 kg / 174,17 lbs.
Keystone -
Illumination -
Frequenz -
Foot-Lamberts 418 fL / max. 1012 cm screen width
Candela m² 1432 cd/m²
Features Full HD 1080P compatible
Eco Mode
Lan network compatible.
Screen Mirroring Optional only Google TV / Fire TV / Apple TV / Roku TV / Xiaomi TV Ads
In Comparison
The Christie CP2315-RGB compared to others not current "Event" projectors.
Ansi-Lumen:
10 Weight:
69
Contrast:
1 dB: 0
Black level:
93 Power cons.: 0
Picture Total Points:35 Projector Total Points:0
Popularity Top 100
9 popularity points 25 popularity points 28 popularity points 11 popularity points 16 popularity points 20 popularity points
Points:
20
Ranking: 451 (From: 590)
Optional Lenses
NameRatioDistanceShift V Shift HZoom
108-322108-XX 2.4-3.9:1 480-780 m Powered
108-328104-XX 1.95-3:1 390-600 m Powered
108-321107-XX 1.75-2.4:1 350-480 m Powered
108-329105-XX 1.5-2.2:1 300-440 m Powered
108-327103-XX 1.39-1.9:1 278-380 m Powered
108-350109-XX 1.2-1.75:1 240-350 m Powered
108-319104-XX 1.05:1 210 m No Zoom
Status 2018 Discontinued (EOL) // Last update of the data: 2026-06-09
