The projector F85 1080p by Barco operates as a DLP device with 11000 ANSI lumens, a HDTV 1920 x 1080 resolution and a contrast of 15000:1. The runtime of the lamp in this model is estimated at 1500 hours before a replacement is necessary. An integrated lens shift provides significant leeway for placement. The lens can be adjusted to precisely align the image even with off-center installations. The optical system is designed for the use of interchangeable lenses, allowing for a tailor-made configuration for almost any throw ratio. The Lens Calculator is available to calculate the exact dimensions. Looking at practical performance, up to 1066 cm can be illuminated with 11000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 711 cm. For media input, video signals up to 1080P are supported. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. The projector was released in 2012 and is officially no longer distributed by Barco.
Display Type
3 x DLP Chip HDTV 16/9 Ti Digital Light Processing Chip
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
4889 Lux
Contrast:
15000:1
Candela pro m²:
1556 cd/m²
Foot-Lamberts:
454 fL
70 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
Nein
Connections
HDMI 1.3a in
DVI-I mit HDCP in
5 BNC RGBHV in
YUV in
S-Video in
Cinch Video in
RS232C Din 9 pin in
RJ45 in
2 x 12V Trigger out
Weitere Anschlüsse optional.
Ceiling Mounting
Yes, is possible.
Power
1080W
Size WxHxD
604 x 250 x 505 mm (23,8"x9,8"x19,9") 76,26 L/dm³
Operating Noise
-
Shift: 70 cm
Shift: 89 cm
Shift: 89 cm
Weight
24,10 kg / 53,13 lbs.
Keystone
-
Illumination
-
Frequenz
H-sync: 15-150 kHz V-sync: 48-190 Hz Range max.: 205 MHz
Full HD 1080P compatible Lens shift Funktion Eco Mode Kensington Slot 24/7 continuous operation capable Remote control with mouse control Lan network compatible.
Full HD 1080P compatible
