| Display Type |
9" EMF CRT
2 4/3 Electromagnetically Focused Tube
|
| Ansi-Lumen |
Projector |
250 |
Screen |
83 Lux (200 cm Screen width) |
| Contrast |
1000:1 full on/off |
-
|
| Black Level |
- |
- |
| Offset |
-
|
| Resolution |
2500 x 2000 |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p |
| Application |
CRT Projection | Very narrow picture width and rooms with very little light. |
| Light Source |
CRT Röhre
|
|
| Light Life |
ca. 10000 - 20000 h. (je nach Anwendung) |
| Operating Costs |
-
|
The projection is too dark.
The screen width should be reduced.
|
|
 |
|
Lux: |
83 Lux |
|
Contrast: |
1000:1 |
|
Candela pro m²: |
27 cd/m² |
|
Foot-Lamberts: |
8 fL |
|
 |
|
|
| |
| • |
|
| Focus |
Manual |
| Zoom |
No Zoom |
| Objective |
F=1,15 High brightness |
| Throw Ratio |
- |
| Audio |
- |
| Connections |
S- Video 4- pin (Y/ C)• RGB or Component Video onBNC connectors (sync on green,separate sync, Standard sync orTri- level sync) |
| Ceiling Mounting |
Yes, is possible. |
| Power |
800W |
| Size WxHxD |
649 x 390 x 1131 mm (25,6"x15,4"x44,5") 286,27 L/dm³
|
| Operating Noise |
34dB |
|
| Weight |
85,00 kg / 187,39 lbs. |
| Keystone |
- |
| Illumination |
- |
| Frequenz |
H-sync: 32-132 kHz
V-sync: 37-210 Hz
Range max.: 180 MHz |
| Foot-Lamberts |
8 fL
/ max. 138 cm screen width |
| Candela m² |
27 cd/m² |
| Features |
 Full HD 1080P compatible
Gamma correction
Password protection
Remote control with backlight
• On-screen menus selectable between English, French, German and Spanish • 48 frequency-related memory banks • Colour temperature adjustment (3200°K, 5400°K, 6500°K, 9300 °K or custom) At 10 peak white: 1,200 lumens ANSI: Boost mode: 300 ANSI (1) lumens Normal mode: 250 ANSI (1) lumens Economy mode: 195 ANSI (1) lumens
|
|
- |
In Comparison
The Barco Cine Max compared to others not current "CRT Projection" projectors. |
| Ansi-Lumen: |
|
47 |
Weight: |
|
80 |
| Contrast: |
|
6 |
dB: |
|
73 |
| Black level: |
|
1 |
Power cons.: |
|
32 |
| Picture Total Points: | 18 |
Projector Total Points: | 62 |
|
| Popularity Top 100 |
|
| Points: |
|
38 |
| Ranking: |
31 (From: 472) |
|
|
|
| Status |
- Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet
Product Sheet english HC
  |
