This projector from Nec utilizes LCD technology, achieving 3600 ANSI lumens and a contrast of 4000:1 at a resolution of XGA 1024 x 768. The runtime of the lamp in this model is estimated at 3800 hours before a replacement is necessary – mathematically sufficient for 5.2 years based on two hours of use per day. Should a perpendicular setup to the screen not be possible, the integrated keystone correction (horizontal and vertical) helps to realign the image into a perfect rectangle. The short-throw capabilities allow for large images at a short projection distance. According to specifications, a 2-meter wide image requires a distance of only 72 cm. A look at the light output reveals: The 3600 ANSI lumens are sufficient to illuminate an image width of up to 523 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 349 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P. Also on board is a local media player that allows reading and playing content directly from storage media. The built-in HDMI-MHL (Mobile High-Definition Link) port enables screen mirroring from a smartphone while simultaneously charging it. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. Equipped with a microphone jack and built-in speakers (20W), audio signals during presentations can be played back directly without an external audio system. Since entering the market in 2015, production has been discontinued; the manufacturer no longer actively offers the model.
Display Type
3 x 0,63" LCD TFT Panel mit MLA XGA 4/3 Liquid Crystal Display with Micro Lense Array
Ansi-Lumen
Projector
3600
Screen
1200 Lux (200 cm Screen width)
Contrast
4000:1 full on/off
4000:1 full on/off
Black Level
0,9000 min. Lumen
0,3 min. Lumen
Offset
63,93% 21 cm over screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel WUXGA 1920 x 1200 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p Media player formats: JPEG
Disc Recognition
DVD | HD Blu-ray (komprimiert) | 3D Blu-ray | 4K UHD Blu-ray
Application
Short Distance | Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Calculated brightness quality The screen width may also be larger. Perfect
72 cm (no Zoom)
Lux:
1200 Lux
Contrast:
4000:1
Candela pro m²:
380 cd/m²
Foot-Lamberts:
111 fL
96 cm
•
Focus
Manual
Zoom
No Zoom
Objective
F=1,8 f=4,78mm
Throw Ratio
0,358:1
Audio
20W
Connections
2 x HDMI mit MHL in
D-sub 15 pin in und out
S-Video in
Cinch Video in
Cinch Stereo in
Mini Jack Audio in und out
RS232C Din 9 pin in
USB Typ A in
RJ45 in
Mikrofon in
Full HD 1080P compatible Direkt Power Off Integrated Mediaplayer Blackboard Modus User logo Eco Mode Password protection PJLink™ Optional Wi-Fi network compatible. Lan network compatible. Short-throw projector Crestron®-Software compatible. Offset und Projektionsverhältnis sind nach Objektivmitte.
Full HD 1080P compatible
