Based on LCD technology, the Panasonic PT-FZ570 projects images in a Stationary environment, with technical specs listing 4500 ANSI lumens, a contrast of 10000:1 and a WUXGA 1920 x 1200 resolution. The manufacturer lists the lamp life at 6000 hours – mathematically sufficient for 8.2 years based on two hours of use per day. Regarding setup flexibility, the model features an optical lens shift function alongside digital keystone correction, allowing for precise alignment; exact values can be calculated using the Lens Shift Calculator. A look at the light output reveals: The 4500 ANSI lumens are sufficient to illuminate an image width of up to 682 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 455 cm. Connectivity for fixed installations is rounded off by an RJ45 port for remote maintenance and an HDBaseT interface, which transmits bundled video, audio, and control data over long cable runs. The projector was released in 2016 and is officially no longer distributed by Panasonic.
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Wide screen width or rooms with plenty of light (over 200 lumens).
HDMI in
D-sub 15pin in und out
Cinch Video in
Cinch Stereo in
Mini Jack Audio in und out
USB Typ A in
RS232C Din 9 pin in
RJ45 mit DIGITAL LINK HDBaseT in
Ceiling Mounting
Yes, is possible.
Power
413W
Size WxHxD
498 x 145 x 398,3 mm (19,6"x5,7"x15,7") 28,74 L/dm³
Operating Noise
33 / 29 dB in Eco Mode
Key: 114 cm Shift: 68 cm
Key: 141 cm Shift: 60 cm
Key: 141 cm Shift: 60 cm
Key: 114 cm Shift: 68 cm
Weight
7,90 kg / 15,43 lbs.
Keystone
Vert.: +/-25° Hori.: +/-30°
Illumination
90%
Frequenz
H-sync: 15-91 kHz V-sync: 24-120 Hz Range max.: 162 MHz
Lens shift Funktion
