Panasonic PT-RW930 E/U/B/W


Panasonic PT RW930W | Panasonic PT RW930U | Panasonic PT RW930E | Panasonic PT RW930UL | Panasonic PT RW930EL | Panasonic PT RW930B | Panasonic PT RW930LB | Panasonic PT RW930JW
Image Panasonic PT-RW930 E/U/B/W
Customer review
Offer Ads
Discover other popular projectors on Amazon!
Model Overview Based on DLP technology, the Panasonic PT-RW930 E/U/ projects images in a Stationary environment, with technical specs listing 9400 ANSI lumens, a contrast of 10000:1 and a WXGA 1280 x 800 resolution. This is a laser projector with a light source designed to last for 20000 hours – equivalent to a usable life of 13.7 years at 4 hours a day. The projector is offered by the manufacturer in both white and black housing variants.
To facilitate room installation, the device is equipped with mechanical lens shift and additional keystone correction, allowing the projected image to be positioned with immense flexibility. For maximum setup flexibility, the model supports optional interchangeable lenses, meaning the optics can be precisely matched to individual on-site requirements. Suitable distances can be determined using the Distance Calculator.
A look at the light output reveals: The 9400 ANSI lumens are sufficient to illuminate an image width of up to 985 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 657 cm. Should very large projection surfaces be required, the integrated edge-blending software offers the possibility to seamlessly combine images from multiple projectors without visible seams.
For media input, video signals up to 1080P are supported. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance.
Since entering the market in 2016, production has been discontinued; the manufacturer no longer actively offers the model. As an archive device, the projector remains highly relevant in our database.
Display Type       1 x 0,65" DLP Chip
      WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
9400
Screen
3760 Lux (200 cm Screen width)
Contrast 10000:1 full on/off 10000:1 full on/off
Black Level 0,9400 min. Lumen 0,376 min. Lumen
Lens shift Vert.: +60% -16% Hori.: +30% -10%
 Lens shift
60%  75cm
16%  20cm
30%  60cm
10%  20cm
+ Projector
Resolution WXGA 1280 x 800
1.024.000 Pixel
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p
Application Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very large screen width and rooms with plenty of light and shaded daylight.
Light Source Laserdiode
Article Nr.: N2QAYA000060
Order Accessories
42,99 €
Light Life 20000 h.
Operating Costs 0,00 € Laser
The screen width should be larger. It's uncomfortably bright in the dark. too bright
360 - 500 cm
Lux: 3760 Lux
Contrast: 10000:1
Candela pro m²: 1196 cd/m²
Foot-Lamberts: 349 fL
75 cm


Screen width:cm
          Room:
Focus Powered
Zoom Powered 1,41
Objective F=1,7-1,9 f=25,6-35,7 mm
Throw Ratio 1,8-2,5:1 show
Audio Nein
Connections HDMI in
DVI-D in
D-sub 15pin in
5 x BNC RGBHV in
RS232C Din 9 pin in
RJ45 in
DIGITAL LINK
Ceiling Mounting Yes, is possible.
Power -
Size WxHxD 498 x 200 x 538 mm (19,6"x7,9"x21,2") 53,58 L/dm³
Operating Noise 41dB
Key: 302 cm
Shift: 75 cm
Key: 96 cm
Shift: 20 cm
Key: 96 cm
Shift: 60 cm
Key: 302 cm
Shift: 20 cm

Weight 23,20 kg / 51,15 lbs.
Keystone Vert.: +/-40°
Hori.: +/-15°
Illumination 90%
Frequenz H-sync: 15-100 kHz
V-sync: 24-120 Hz
Foot-Lamberts 349 fL / max. 985 cm screen width
Candela m² 1196 cd/m²
Features Full HD 1080P compatible
Lens shift Funktion
Eco Mode
360° installable
24/7 continuous operation capable
Edge Blending
PJLink™
Lan network compatible.
Picture-in-picture
DICOM simulation
Screen Mirroring Optional only Google TV / Fire TV / Apple TV / Roku TV / Xiaomi TV Ads
In Comparison
The Panasonic PT-RW930 E/U/B/W compared to others not current "Stationary" projectors.
Ansi-Lumen:
94 Weight:
91
Contrast:
1 dB:
93
Black level:
97 Power cons.: 0
Picture Total Points:64 Projector Total Points:0
Popularity Top 100
12 popularity points 13 popularity points 15 popularity points 3 popularity points 16 popularity points 7 popularity points
Points:
7
Ranking: 142 (From: 2536)
Optional accessories
object lens OriginalET-DLE1502.249,61 €
object lens OriginalET-DLE0604.005,06 €
object lens OriginalET-DLE1053.447,07 €
ceiling bracket OriginalET-PKD130BEOL €
ceiling bracket OriginalET-PKD120SEOL €
ceiling bracket OriginalET-PKD120HEOL €
Lens Used OriginalET-DLE2502.249,61 €
lens Used OriginalET-DLE150Z1.839,23 €
lens Used OriginalET-DLE4501.482,23 €
lens Used OriginalET-DLE3502.249,61 €
lens Used OriginalET-DLE0304.363,33 €
object lens OriginalET-DLE0553.447,07 €
lens Used OriginalET-DLE0852.811,38 €
remote control OriginalN2QAYA00006042,99 €
ceiling bracket white Halterung45W83,60 €
Optional Lenses
NameRatioDistanceShift V Shift HZoom
ET-DLE450 5.5-8.9:1 1100-1780 m 60-16% 30-10% Powered
ET-DLE350 3.8-5.7:1 760-1140 m 60-16% 30-10% Powered
ET-DLE250 2.4-3.8:1 480-760 m 60-16% 30-10% Powered
ET-DLE150 1.4-2:1 280-400 m 60-16% 30-10% Powered
ET-DLE105 1-1.4:1 200-280 m 60-16% 30-10% Powered
ET-DLE085 0.8-1:1 160-200 m 60-16% 28-10% Powered
ET-DLE060 0.63-0.84:1 126-168 m 0.00% Fix Powered
ET-DLE055 0.8:1 160 m 0.00% Fix No Zoom
ET-DLE030 0.4:1 80 m 70% Fix No Zoom
Status 2016 Discontinued (EOL) // Last update of the data: 2026-06-09
