The Panasonic PT-RZ34K is a 3D-Laser-DLP projector offering 30500 ANSI lumens, a contrast of 20000:1 and a resolution of WUXGA 1920 x 1200. The laser technology ensures a specified light source lifespan of up to 20000 hours, covering an estimated 13.7 years based on a 4-hour daily runtime. Both optical image shifting (lens shift) and digital keystone adjustment are included, enabling exact alignment on the screen. The specifications identify the device as a model with an interchangeable lens option. Matching optional optics allow for exact adaptation to the required image size and projection distance, which can be calculated directly with the Distance Calculator. Regarding projection size, the value of 30500 ANSI lumens allows for an image width of up to 1774 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 1183 cm. Regarding signal processing, the model is compatible with incoming 1080P content and 4K as well as 3D. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket.
Display Type
3 x 0,96" DLP Chip WUXGA 16/9 Ti Digital Light Processing Chip
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
13556 Lux
Contrast:
20000:1
Candela pro m²:
4314 cd/m²
Foot-Lamberts:
1259 fL
62 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
Nein
Connections
HDMI in
BNC in und out
D-sub 15pin in und out
Wired Remote in
USB in
RS232C Din 9 pin in
RJ45 in
BNC x 1: 3G/HD-SDI input
DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP) (Single-link only)
3D SYNC IN/OUT
Ceiling Mounting
Yes, is possible.
Power
-
Size WxHxD
600 x 360 x 800 mm (23,6"x14,2"x31,5") 172,8 L/dm³
Real Full HD 3D Full HD 1080P compatible Lens shift Funktion Eco Mode Kensington Slot 360° installable PJLink™ Optional Wi-Fi network compatible. Lan network compatible. NFC via ET-NUK10 optional.
Real Full HD 3D
