The equipment of the Acer U5320W projector includes 3000 ANSI lumens, a contrast of 13000:1 with a WXGA 1280 x 800 display. The manufacturer lists the lamp life at 3000 hours. The short-throw capabilities allow for large images at a short projection distance. According to specifications, a 2-meter wide image requires a distance of only 74 cm. Looking at practical performance, up to 556 cm can be illuminated with 3000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 371 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P as well as 3D. Thanks to MHL support, screen content from mobile devices can be transmitted via cable, including charging power for the device. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. Equipped with a microphone jack and built-in speakers (10W), audio signals during presentations can be played back directly without an external audio system. Since entering the market in 2015, production has been discontinued; the manufacturer no longer actively offers the model.
Display Type
1 x 0,65 DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3000 / 2400 im Eco Mode
Screen
1200 Lux (200 cm Screen width)
Contrast
13000:1 full on/off
13000:1 full on/off
Black Level
0,2308 min. Lumen
0,092 min. Lumen
Offset
74% 30 cm over screen top edge →
SCREEN
+Projector
Resolution
WXGA 1280 x 800
1.024.000 Pixel WUXGA 1920 x 1200 compressed
Calculated brightness quality The screen width may also be larger. Perfect
74 cm (no Zoom)
Lux:
1200 Lux
Contrast:
13000:1
Candela pro m²:
380 cd/m²
Foot-Lamberts:
111 fL
93 cm
•
Focus
Manual
Zoom
No Zoom
Objective
F=2,53 f=5,38mm
Throw Ratio
0,37:1
Audio
1 x 10W
Connections
2 x HDMI mit MHL in
2 x D-sub 15pin in 1 x out
Cinch Video in
Cinch Stereo in
S-Video in
Mini Jack Audio in und out
USB Typ A,B in
RS232C Din 9 pin in
RJ45 in
Mikrofon in
Real Full HD 3D Full HD 1080P compatible Eco Mode Kensington Slot BrilliantColor™ Lan network compatible. Short-throw projector Crestron®-Software compatible. 6-segment colour wheel and ACBII+ Digital zoom 2x
Real Full HD 3D
