| Display Type |
7" ESF CRT
SXGA 5/4 Electrostatically Focused Tube
|
| Ansi-Lumen |
Projector |
160 / 800 peaker white |
Screen |
50 Lux (200 cm Screen width) |
| Contrast |
1000:1 full on/off |
-
|
| Black Level |
- |
- |
| Offset |
-
|
| Resolution |
SXGA 1280 x 1024
1.310.720 Pixel |
| Video Modes |
NTSC, PAL, SECAM, NTSC 4.43, PAL-M & N HDTV |
| Application |
CRT Projection | Very narrow picture width and rooms with very little light. |
| Light Source |
CRT Röhre
|
|
| Light Life |
ca. 10000 - 20000 h. (je nach Anwendung) |
| Operating Costs |
-
|
The projection is too dark.
The screen width should be reduced.
|
|
 |
|
Lux: |
50 Lux |
|
Contrast: |
1000:1 |
|
Candela pro m²: |
17 cd/m² |
|
Foot-Lamberts: |
5 fL |
|
 |
|
|
| |
| • |
|
| Focus |
Manual |
| Zoom |
No Zoom |
| Objective |
F=1,1 f=135mm |
| Throw Ratio |
- |
| Audio |
- |
| Connections |
Bitte entnehmen sie Daten der PDF Datei |
| Ceiling Mounting |
Yes, is possible. |
| Power |
450W standby 7W |
| Size WxHxD |
603 x 345 x 671 mm (23,7"x13,6"x26,4") 139,59 L/dm³
|
| Operating Noise |
- |
|
| Weight |
54,00 kg / 119,05 lbs. |
| Keystone |
- |
| Illumination |
- |
| Frequenz |
H-sync: 15-64 kHz
V-sync: 38-150 Hz
Range max.: 75 MHz |
| Foot-Lamberts |
5 fL
/ max. 107 cm screen width |
| Candela m² |
17 cd/m² |
| Features |
- |
|
- |
In Comparison
The Sony VPH D50HTM compared to others not current "CRT Projection" projectors. |
| Ansi-Lumen: |
|
1 |
Weight: |
|
90 |
| Contrast: |
|
6 |
dB: |
|
0 |
| Black level: |
|
1 |
Power cons.: |
|
69 |
| Picture Total Points: | 3 |
Projector Total Points: | 0 |
|
| Popularity Top 100 |
|
| Points: |
|
29 |
| Ranking: |
108 (From: 472) |
|
|
|
|
|
| Status |
- Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet english
Product Sheet english HC
Serial Port
User Manual english (2.65 MB)
User Manual english (0.99 MB)
 |
