The projector HY300 by Quilted Northern operates as a LED-LCD device with 160 ANSI lumens, a HDTV 1920 x 1080 resolution and a contrast of 1500:1. The LED unit of this model is rated for up to 30000 hours of runtime, which translates to 20.5 years with 4 hours of daily use. The image geometry can be adjusted via the built-in keystone correction so that a clean, rectangular display is achieved even with non-ideal placement. Regarding projection size, the value of 160 ANSI lumens allows for an image width of up to 129 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 86 cm. Regarding signal processing, the model is compatible with incoming 1080P content and 4K. Also on board is a local media player that allows reading and playing content directly from storage media. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Thanks to support for Miracast and Airplay, screen content can also be cast wirelessly from a smartphone, tablet, or PC to the screen. Regarding noise emissions, the model proves to be exceptionally quiet during operation, producing just 25 decibels.
Display Type
1 x LCD TFT Panel HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
160
Screen
71 Lux (200 cm Screen width)
Contrast
1500:1 full on/off
1500:1 full on/off
Black Level
0,1067 min. Lumen
0,047 min. Lumen
Offset
-
Resolution
HDTV 1920 x 1080
2.073.600 Pixel UHD (4K2K) 3840 x 2160 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p Media player formats: Mediaplayer
Application
Game-Portabel | Very portable, small-screen projections. Very narrow picture width and rooms with very little light.
Light Source
LED
Light Life
30000 h.
Operating Costs
0,00 € LED
The projection is too dark. The screen width should be reduced.
Lux:
71 Lux
Contrast:
1500:1
Candela pro m²:
24 cd/m²
Foot-Lamberts:
7 fL
•
Focus
Automatic
Zoom
No Zoom Digital Zoom
Objective
-
Throw Ratio
-
Audio
Built-in loudspeaker
Connections
HDMI in
AV in
USB in
Audio Mini Jack out
Bluetooth 5.2
Full HD 1080P compatible
Product Sheet english HC
