Known as the LC X983, this LCD projector by Eiki features basic specs of 1600 ANSI lumens, a contrast of 350:1 at a XGA 1024 x 768 resolution. The manufacturer rates the durability of the included lamp at 2000 hours. A look at the light output reveals: The 1600 ANSI lumens are sufficient to illuminate an image width of up to 348 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 232 cm. This model dates back to 2000 and is no longer part of Eiki's current product range.
Display Type
3 x 1,3 LCD TFT PSI Panel mit MLA XGA 4/3 Liquid Crystal Display with Micro Lense Array
Ansi-Lumen
Projector
1600
Screen
533 Lux (200 cm Screen width)
Contrast
350:1 full on/off
350:1 full on/off
Black Level
4,5714 min. Lumen
1,536 min. Lumen
Offset
45% 7 cm under screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel
SXGA 1280 x 1024 compressed
Video Modes
PAL/PAL-M&N/SECAM/NTSC/NTSC4.43
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
Computer-Eingänge 2 x D-SUB 15
2 x 3,5 mm Klinke (Stereo) für Audio
Computer-Ausgänge 1 x D-SUB 15
AV-Eingänge 1 x RCA, 1 x S-Video, 2 x RCA (Audio- R, L)
3 x RCA (Y, B-Y, R-Y) - Komponente
Weitere Ein- und Ausgänge 2 x DIN 8 Pin für Maussteuerung und serielle Schnittstelle
1 x 3,5 mm Klinke (Stereo) für Audio
Ceiling Mounting
Yes, is possible.
Power
300W
Size WxHxD
272 x 145 x 412 mm (10,7"x5,7"x16,2") 16,25 L/dm³
Operating Noise
-
Key: 278 cm
Key: 142 cm
Weight
6,60 kg / 14,55 lbs.
Keystone
Vert.: +/-30°
Illumination
-
Frequenz
H-sync: 15-100 kHz V-sync: 50-100 Hz Range max.: 165 MHz
Kensington Slot
Eiki Contact
Product Sheet english
