The LC XT4 model from Eiki combines LCD technology in the Event sector with 12000 ANSI lumens, a contrast of 1300:1 and a native XGA 1024 x 768 resolution. The manufacturer specifies a runtime of 2000 hours for this projector's lamp. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. To meet a wide variety of installation conditions, the projector offers the option of using different interchangeable lenses. Verifying the respective distances is easily possible via the Projector Calculator. A look at the light output reveals: The 12000 ANSI lumens are sufficient to illuminate an image width of up to 954 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 636 cm. Since entering the market in 2006, production has been discontinued; the manufacturer no longer actively offers the model. However, it remains frequently searched within our database.
The screen width should be larger. It's uncomfortably bright in the dark. too bright
Lux:
4000 Lux
Contrast:
1300:1
Candela pro m²:
1275 cd/m²
Foot-Lamberts:
372 fL
75 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
2 x 3W Stereo
Connections
Input 1:
1 x DVI-I (Digital und Analog)
2 x RCA (R, L) für Audio,
1 x Mini DIN 8-PIN (Maus-Kontroll-Anschluß)
Input 2:
1 x BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr),
2 x RCA (R, L) für Audio
1 x Mini DIN 8-PIN (Maus-Kontroll-Anschluß)
Input 3:
2 x BNC Composite und S-Video
1 x Mini DIN 4-PIN S-Video,
2 x RCA (R, L)
Input 4:
1 x D-SUB 15
2 x RCA (R, L)
1 x Mini DIN 8-PIN (Maus-Kontroll-Anschluß)
Ceiling Mounting
Yes, is possible.
Power
1700W
Size WxHxD
581 x 252 x 783 mm (22,9"x9,9"x30,8") 114,64 L/dm³
Operating Noise
46dB
Shift: 75 cm
Shift: 20 cm
Shift: 20 cm
Shift: 75 cm
Weight
36,50 kg / 80,47 lbs.
Keystone
Vert.: +/-30°
Illumination
-
Frequenz
H-sync: 15-120 kHz V-sync: 50-120 Hz Range max.: 230 MHz
Lens shift Funktion motorisch max. Freeze Gamma correction 24/7 continuous operation capable Remote control with laser pointer und mouse control Optional LAN network compatible. Angaben im Prospekt englisch sind mit vorsicht zu beachten.
Lens shift Funktion motorisch max.
