As a projector, the 3M MP 8780 combines LCD technology with a resolution of XGA 1024 x 768, and is additionally specified with 2300 ANSI lumens and a contrast of 200:1. According to 3M, the lamp has a durability of 1000 hours. A look at the light output reveals: The 2300 ANSI lumens are sufficient to illuminate an image width of up to 418 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 279 cm. This model dates back to 1999 and is no longer part of 3M's current product range.
XGA 1024 x 768
786.432 Pixel
SXGA 1280 x 1024 compressed
Video Modes
NTSC, PAL, SECAM, NTSC 4.43, PAL-M, PAL-N
Application
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Medium screen width or rooms with little light, max. 100 lumens.
S-Video: (1) Mini DIN 4-pin
Video: (1) RCA jack
Audio: (2) RCA jack und (2) mini stereo
RGB: (2) Mini-D-sub 15pin (2) stereo mini pin jack
(5) BNC
• Output terminals:
Audio: (1) 3.5 stereo mini jack
RGB: (1) Mini D-sub 15-pin (female)
Maus control und RS232C: (1) Mini D sub 15 pin (male)
Freeze
