Designed for the Stationary sector, the MC WX8751W model from Maxell features 7500 ANSI lumens, a native WXGA 1280 x 80 resolution and a contrast ratio of 10000:1. In operating mode, the installed projector lamp offers a lifespan of 2000 hours. Regarding setup flexibility, the model features an optical lens shift function alongside digital keystone correction, allowing for precise alignment without distortion. The specifications identify the device as a model with an interchangeable lens option. Matching optional optics allow for exact adaptation to the required image size and projection distance, which can be calculated directly with the Distance Calculator. Looking at practical performance, up to 880 cm can be illuminated with 7500 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 587 cm. For media input, video signals up to 1080P are supported. An additional 360° projection capability allows the device to be oriented at almost any angle. Also on board is a local media player that allows reading and playing content directly from storage media. The model is perfectly equipped for complex installations: In addition to the RJ45 jack for network administration, an HDBaseT port is available, transporting high-resolution AV signals over a single Cat cable. This model dates back to 2016 and is no longer part of Maxell's current product range.
Display Type
3 x LCD TFT Panel WXGA 16/10 Liquid Crystal Display
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p Media player formats: • JPEG (.jpeg, .JPEG)
• Bitmap (.bmp)
• PNG (.png)
• GIF (.gif)
• Movie (.avi, .mov)
Application
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Very large screen width and rooms with plenty of light and shaded daylight.
2 x HDMI in
D-sub 15 pin in und out
SDI in
S-Video in
Cinch Video in
Cinch Stereo in
USB Typ A,B in
Mini Jack Audio in und out
RS232C Din 9 pin
RJ45 mit HDBaseT in
Ceiling Mounting
Yes, is possible.
Power
580 / 560W in Eco Mode
Size WxHxD
497,8 x 154,9 x 426,7 mm (19,6"x6,1"x16,8") 32,61 L/dm³
Full HD 1080P compatible Lens shift Funktion Integrated Mediaplayer Freeze Blackboard Modus User logo Eco Mode Automatic and manual vertical keystone correction Kensington Slot 360° installable Picture-in-Picture Password protection PJLink™ Control via web browser Optional Wi-Fi network compatible. Lan network compatible. Crestron®-Software compatible. Picture-by-picture
Full HD 1080P compatible
Product Sheet english
