The LV 7510 model from Canon combines LCD technology in the Standard-Portabel sector with 1900 ANSI lumens, a contrast of 350:1 and a native XGA 1024 x 768 resolution. According to Canon, the lamp has a durability of 2000 hours. A look at the light output reveals: The 1900 ANSI lumens are sufficient to illuminate an image width of up to 380 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 253 cm. Since entering the market in 1999, production has been discontinued; the manufacturer no longer actively offers the model.
XGA 1024 x 768
786.432 Pixel
SXGA 1280 x 1024 compressed
Video Modes
NTSC, PAL, SECAM, NTSC 4.43 or PAL-M
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
S video (4 pin din) x 1,
Composite Video x 1,
Audio pin (L/R) x 1set
Composite video x 1,
Stereo audio x 1
HDB 15 pin x 2,
Mini stereo audio x 2,
Multi-pole 12 pin x 2
D-sub 15pin out x 1
8 pin din serial x 1
digital zoom
