The F1 SXGA wide model from projectiondesign combines DLP technology in the Standard-Portabel sector with 3000 ANSI lumens, a contrast of 1000:1 and a native SXGA 1280 x 1024 resolution. The runtime of the lamp in this model is estimated at 2000 hours before a replacement is necessary. The image geometry can be adjusted via the built-in keystone correction so that a clean, rectangular display is achieved even with non-ideal placement. Regarding projection size, the value of 3000 ANSI lumens allows for an image width of up to 464 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 309 cm. A look at the data sheet confirms a very subtle fan noise for the projector at just 28 decibels. This device is no longer manufactured and has been removed from projectiondesign's current lineup.
Display Type
1 chip DLP DDR (Double Data Rate) SXGA 5/4 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3000
Screen
938 Lux (200 cm Screen width)
Contrast
1000:1 full on/off
1000:1 full on/off
Black Level
3,0000 min. Lumen
0,941 min. Lumen
Offset
-
Resolution
SXGA 1280 x 1024
1.310.720 Pixel
Video Modes
HDTV (1080i, 720p, 576i/p, 480i/p)
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Medium screen width or rooms with a little more ambient light, max. 200 lumens.
2 D sub 15 Pin (Analog RGB)
1 DVI (Digital RGB)
1 Component video (SDTV/HDTV)
1 S-video
1 Composite video
4 Stereo Mini jack audio
1 RS232 9-pin DSUB (control)
1 USB (Maus und firmware upgrade)
1 VGA monitor out
1 Stereo Mini jack audio
Freeze User logo Eco Mode Kensington Slot sRGB Gamma correction 24/7 continuous operation capable Remote control with laser pointer und mouse control Faroudja DCDi with automatic film mode detection (3:2 and 2:2 pulldown)
Freeze
