Brief Introduction
Beta 2.5 |
The standard portable 3M Nobile X50 LCD projector has 2000 Ansi lumens, a contrast of 400:1 and an XGA 1024 x 768 resolution. As the projector has horizontal and vertical keystone correction, the projector can be set up with plenty of free space in the room. The projector can illuminate a picture width of up to 389 cm thanks to its 2000 Ansi lumens. In room lighting, however, the picture width should ideally be less than 259 cm. This model is no longer available from 3M.
|
| Display Type |
3 x 0,7" LCD TFT Panel
XGA 4/3 Liquid Crystal Display
|
| Ansi-Lumen |
Projector |
2000 / 1600 im Eco Mode |
Screen |
667 Lux (200 cm Screen width) |
| Contrast |
400:1 full on/off |
400:1 full on/off
|
| Black Level |
5,0000 min. Lumen |
1,68 min. Lumen |
| Offset |
45% show
|
| Resolution |
XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
NTSC, NTSC 4,43, PAL, PAL-M,PAL-N, SECAM HDTV 480i, 480p, 525i, 525p, 720p, 1080i |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens. |
| Light Source |
150W UHB Lamp
Article Nr.: EP7650LK / 78-6969-9599-8
|
|
| Light Life |
2000 h. 4000 h. in Eco Mode |
| Operating Costs |
-
|
|
302 - 362 cm
|
 |
|
Lux: |
667 Lux |
|
Room light max.: |
133 Lux |
|
Candela pro m²: |
212 cd/m² |
|
Foot-Lamberts: |
62 fL |
|
 |
| 68 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,2 |
| Objective |
F=1,7-1,9 f=21,7-26,1 mm |
| Throw Ratio |
1,51-1,81:1 show |
| Audio |
1 x1W |
| Connections |
D-sub 15pin in
S-Video in
YUV in
Cinch Video in
Cinch Stereo in
Serieller Anschluss
USB |
| Ceiling Mounting |
Yes, is possible. |
| Power |
240W |
| Size WxHxD |
289 x 76 x 210 mm (11,4"x3"x8,3") 4,61 L/dm³
|
| Operating Noise |
34 / 32 dB in Eco Mode |
Key: 149 cm |
Key: 26 cm |
| Key: 26 cm |
| |
|
|
| Weight |
2,70 kg / 5,95 lbs. |
| Keystone |
Vert.: +/-15°
Hori.: +/-5°
|
| Illumination |
- |
| Frequenz |
H-sync: 31-91 kHz
V-sync: 56-120 Hz
|
| Foot-Lamberts |
62 fL
/ max. 389 cm screen width |
| Candela m² |
212 cd/m² |
| Features |
 Freeze
Blank (Black screen button)
User logo
Eco Mode
Gamma correction
Remote control with mouse control
Overscan adjustable
|
|
- |
In Comparison
The 3M Nobile X50 compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
23 |
Weight: |
|
87 |
| Contrast: |
|
1 |
dB: |
|
38 |
| Black level: |
|
81 |
Power cons.: |
|
98 |
| Picture Total Points: | 35 |
Projector Total Points: | 74 |
|
| Popularity Top 100 |
|
| Points: |
|
8 |
| Ranking: |
2532 (From: 7662) |
|
|
|
|
|
| Status |
- Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet english
Product Sheet english HC
Quick Start Guide
User Manual english (2.85 MB)
|
|
|
Autor:
Chris 20.04.15 |
|
5 Stars |
Pioneering, but with signs of age |
|
2015 no longer quite up to date, but still: quality still pays off ten years later. Flawless picture, clear contrasts, good smoothness ... beautiful picture, I don‘t miss anything.
|
|
|
Autor:
Mario 29.02.12 |
|
5 Stars |
judgement |
|
great beamer, crisp (despite sunlight) and huge picture, excellent color reproduction
|
|
|
Autor:
weh 17.10.10 |
|
2.5 Stars |
@michael |
|
check out the rectifier D5SBA60
|
|
|
Autor:
Michael 28.07.10 |
|
3.8 Stars |
Power supply defective |
|
Hello everyone
does anyone have a service manual? I suspect my power supply is defective - short circuit when switching on, fuse blown. It would be a shame if the projector ends up like this after only 350 hours of operation.
|
|
|
Autor:
Peter 20.12.09 |
|
1 Stars |
Replacement |
|
Does anyone happen to have a replacement LCD (blue) for this projector ours is broken
please contact us at [email protected]
|
|
|
Autor:
Peter Kaiser 20.12.09 |
|
1 Stars |
Replacement |
|
Does anyone happen to have a replacement LCD (blue) for this projector ours is broken
please contact us at [email protected]
|
|
|
|
