Brief Introduction
Beta 2.5 |
The standard portable KG PV131Xh25 BrilliantColor DLP has 2500 Ansi lumens, a contrast of 2000:1 and an XGA 1024 x 768 resolution. An image width of up to 435 cm is possible as the projector has 2500 Ansi lumens. However, if room light is available, the picture should be max. 290 cm wide. On the market since 2008, the model is no longer offered by the manufacturer TAXAN.
|
| Display Type |
1 x 0,55" DLP Chip
XGA 4/3 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
2500 |
Screen |
833 Lux (200 cm Screen width) |
| Contrast |
2000:1 full on/off |
2000:1 full on/off
|
| Black Level |
1,2500 min. Lumen |
0,417 min. Lumen |
| Offset |
60,5% show
|
| Resolution |
XGA 1024 x 768
786.432 Pixel |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens. |
| Light Source |
230W Lamp
Article Nr.: KGPLS2230
|
|
| Light Life |
2000 h. |
| Operating Costs |
|
|
332 - 384 cm
|
 |
|
Lux: |
833 Lux |
|
Room light max.: |
167 Lux |
|
Candela pro m²: |
264 cd/m² |
|
Foot-Lamberts: |
77 fL |
|
 |
| 91 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,15 |
| Objective |
F=2,45-2,62 f=18,7-21,5 mm |
| Throw Ratio |
1,66-1,92:1 show |
| Audio |
0,5W Mono |
| Connections |
2 x D-sub 15 pin in 1 x out
S-Video in
Cinch Video in
RS232C Din 9 pin in
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
300 / 245W in Eco Mode |
| Size WxHxD |
260 x 58 x 210 mm (10,2"x2,3"x8,3") 3,17 L/dm³
|
| Operating Noise |
33 / 30 dB in Eco Mode |
|
| Weight |
1,90 kg / 4,19 lbs. |
| Keystone |
- |
| Illumination |
- |
| Frequenz |
H-sync: 15-80 kHz
V-sync: 50-85 Hz
|
| Foot-Lamberts |
77 fL
/ max. 435 cm screen width |
| Candela m² |
264 cd/m² |
| Features |
 Freeze
Eco Mode
Automatic and manual vertical keystone correction
Kensington Slot
Password protection
BrilliantColor™
Digital Zoom
Lens shutter
|
|
- |
In Comparison
The TAXAN KG PV131Xh25 compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
29 |
Weight: |
|
91 |
| Contrast: |
|
1 |
dB: |
|
41 |
| Black level: |
|
95 |
Power cons.: |
|
97 |
| Picture Total Points: | 42 |
Projector Total Points: | 76 |
|
| Popularity Top 100 |
|
| Points: |
|
4 |
| Ranking: |
6739 (From: 7662) |
|
|
|
|
|
| Status |
2008 Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet english
Product Sheet english HC
|
