As a projector for the Micro-Portabel sector, the Byintek U80 Max is equipped with 500 ANSI lumens, a HDTV 1920 x 1080 resolution and a contrast of 20000:1. The manufacturer specifies a durability of 50000 hours for the LED light source, covering an estimated 34.2 years based on a 4-hour daily runtime. For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups. To reduce dependence on stationary power sources, the model is equipped with a built-in battery for autonomous operation. Regarding projection size, the value of 500 ANSI lumens allows for an image width of up to 227 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 151 cm. Additionally, a built-in ambient light sensor measures the room lighting and automatically adjusts the projection settings. Regarding signal processing, the model is compatible with incoming 1080P content and 4K. As an additional feature, an integrated media player enables the direct playback of files without an external source device. For wireless audio output, the projector also supports Bluetooth, making it easy to quickly connect external soundbars. Since the projector supports Miracast and Airplay screen mirroring, video signals can also be streamed wirelessly from the end device. With a value of only 28 decibels, the noise level during operation remains pleasantly in the background.
Display Type
1 x 0,23" Ti DMD DLP Chip HDTV 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
500
Screen
222 Lux (200 cm Screen width)
Contrast
20000:1 full on/off
20000:1 full on/off
Black Level
0,0250 min. Lumen
0,011 min. Lumen
Offset
-
Resolution
HDTV 1920 x 1080
2.073.600 Pixel UHD (4K2K) 3840 x 2160 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p Media player formats: Unterstützung für synchrone Anzeige über USB-Kabel für iOS-Geräte und einige Android-Geräte
Videodecoder: AV1 MP-10 4K2K@60fps, H.265 HEVC MP-10@L5.1 bis zu 4K2K@60fps, VP9 Profile-2 bis zu 4K2K@60fps, AVS2-P2 bis zu 4K2K@60fps, H.264 AVC HP bis 4K*2K@30fps, MPEG-4 ASP@L5 bis 1080P@60fps, MPEG-2 MP/HL bis 1080P@60fps, MPEG-1 MP/HL bis 1080P@60fps, AVS+ JiZhun Profile bis 1080P@60fps
Videoformate: MKV, MPG, MPEG, DAT, MP4
Audio-Decoder: MPEG1/2, MP3, AAC/HE-AAC, FLAC, OGG, DD, DD+
Audioformate: MPEG1/2, MP3, AAC
Full HD 1080P compatible Integrated Mediaplayer Automatic and manual vertical keystone correction High Dynamic Range (HDR) Remote control with mouse control Wi-Fi network compatible. Ambient Light Sensor. 15000mAh Android 11.0 MEMC
Full HD 1080P compatible
