PDF/Print Version: Sonnoc SNP-LU75KC Projector

Order

Brief Introduction

Beta 2.5

A brief introduction to the SNP-LU75KC: The Sonnoc Stationary 3D Laser DLP projector offers 7700 ANSI lumens, a contrast of 3000000:1 and a WUXGA 1920 x 1200 resolution. The manufacturer specifies a laser lifespan of 200,000 hours, which would be 13.7 years with 4 hours of viewing per day. The built-in lens shift and keystone correction function provides freedom when adjusting the projection. The projector can illuminate up to 892 cm of image width well with its 7700 ANSI lumens. The projector can handle rooms with low light, but we would recommend a smaller image width for rooms with more light. Furthermore, the projector can play 1080P and 4K (compressed) as well as 3D without any problems, and thus all currently available Blu-ray formats can be recognized by the projector. With only 30 decibels of operating noise, the model is already very quiet compared to others.

Display Type

1 x 0,67" DMD DLP Chip
WUXGA 16/9 Ti Digital Light Processing Chip

Ansi-Lumen

Projector

7700

Screen

3422 Lux (200 cm Screen width)

Contrast

3000000:1

Black Level

0,0026 min. Lumen

0,001 min. Lumen

Offset

Resolution

WUXGA 1920 x 1200
2.304.000 Pixel
UHD (4K2K) 3840 x 2160 compressed

Video Modes

Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), 3D, EDTV 480p, 576p

3D Compatibility

Frame-Packing (Full HD 3D) | Side-by-Side | Top-and-Bottom
Frame Sequential (3D Ready)

Application

Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very large screen width and rooms with plenty of light and shaded daylight.

Light Source

MCL Laser Diode

Light Life

20000 h. Normal / 25000 h. Eco

Operating Costs

0,00 € Laser

130 - 150 cm


	Lux:	3422 Lux
	Room light max.:	684 Lux
	Candela pro m²:	1090 cd/m²
	Foot-Lamberts:	318 fL

Focus

Powered

Zoom

Powered 1,1538

Objective

optional

Throw Ratio

0,65-0,75:1

Audio

2 x 10W

Connections

HDMI 2.0 in
2x HDMI 2.0 (HDCP)
3D Sync in und out
Mini Jack Audio out
USB-A in
RS232C Din 9 pin in
Wired Remote 3,5mm
RJ45 in
HDBaseT

Ceiling Mounting

Yes, is possible.

Power

405W

Size WxHxD

486 x 181 x 376 mm (19,1"x7,1"x14,8") 33,08 L/dm³

Operating Noise

30 / 25 dB in Eco Mode

Key: 109 cm
Key: 75 cm	Without offset	Key: 75 cm
	Key: 109 cm

Weight

11,50 kg / 24,25 lbs.

Keystone

Vert.: +/-40°
Hori.: +/-30°

Illumination

90%

Frequenz

Foot-Lamberts

318 fL / max. 892 cm screen width

1090 cd/m²

Features

Real Full HD 3D

Full HD 1080P compatible

Eco Mode

High Dynamic Range (HDR)

Warping

360° installable

24/7 continuous operation capable

Optional Wi-Fi network compatible.

Lan network compatible.

Color Management System

Screen Mirroring

In Comparison

The Sonnoc SNP-LU75KC compared to others current "Stationary" projectors.

Ansi-Lumen:

Weight:

Contrast:

dB:

Black level:

100

Power cons.:

Picture Total Points:

Projector Total Points:

Popularity Top 100

Points:

Ranking:

55 (From: 231)

Optional accessories
	Deckenhalterung Länge 225 mm	Halterung45	85,80 €

Standard-Lens

Optional Lenses

Name	Ratio	Distance	Shift V	Shift H	Zoom
Zoom Optional Lenses
Standard 1.2-1.5	1.2-1.5:1	2.4-3 m			Powered
Standard 0.7-1.2	0.7-1.2:1	1.4-2.4 m			Powered
Optional 2.90-5.50	2.9-5.5:1	5.8-11 m			Powered
Optional 1.52-2.92	1.52-2.92:1	3-5.8 m			Powered
Optional 0.65-0.75	0.65-0.75:1	1.3-1.5 m			Powered
Fix Optional Lenses
Standard 0.55	0.55:1	1.1 m			No Zoom

Status

2024 Current model // Last update of the data: 2024-11-15

Data

Sonnoc Website

Product Sheet english HC

More Details


	https://www.projector-database.com/pro/sonnocsnplu75kc-en.html

Due to our ongoing commitment to continuously improve the quality of our projector database, this brochure is also subject to change without notice. HCinema is not responsible for any errors or omissions contained in product descriptions.
