PDF/Print Version: Epson EB G5150/NL Projector

Brief Introduction

Beta 2.5

The standard portable EB G5150/NL LCD projector from Epson has 4000 Ansi-Lumen, a contrast of 1000:1 and an XGA 1024 x 768 resolution. The projector is equipped with an integrated media player, so direct playback of files will not be a problem. With the lens shift function, the projector can be positioned very freely. 4000 Ansi lumens ensure that a picture width of 551 cm is also possible. The projector manages rooms with residual light with a smaller image width, we recommend a maximum of 367 cm. Playing 1080P is also no problem for the projector. This model is no longer offered by Epson.

Display Type

3 x 0,8" LCD TFT Panel mit MLA
XGA 4/3 Liquid Crystal Display with Micro Lense Array

Ansi-Lumen

Projector

4000 / 3200 im Eco Mode

Screen

1333 Lux (200 cm Screen width)

Contrast

1000:1 full on/off

Black Level

4,0000 min. Lumen

1,337 min. Lumen

Lens shift

Vert.: +/-50% Hori.: +/-10%

Resolution

XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed

Video Modes

PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p
Media player formats: JPEG/BMP/GIF/PNG, Film: MPEG2/MPEG4 ASP/MPEG4 AVC(H.264)/WMV8,9

Application

Standard-Portabel | External training and company presentations, as well as product presentations.
Wide screen width or rooms with plenty of light (over 200 lumens).

Light Source

210W UHE Lamp
Article Nr.: ELPLP47 / V13H010L47

Light Life

2000 h. 3000 h. in Eco Mode

Operating Costs

1067 - 1442 cm


	Lux:	1333 Lux
	Room light max.:	267 Lux
	Candela pro m²:	425 cd/m²
	Foot-Lamberts:	124 fL

75 cm

Focus

Manual

Zoom

Manual 1,35

Objective

optional

Throw Ratio

5,337-7,212:1

Audio

7W Mono

Connections

D-sub 15 pin in und out
5 x BNC RGBHV in
S-Video in
Cinch Video in
Cinch Stereo in
RJ45 in
RS232C
SD Card Slot
USB Typ A, B

Ceiling Mounting

Yes, is possible.

Power

327W

Size WxHxD

470 x 135 x 311,5 mm (18,5"x5,3"x12,2") 19,73 L/dm³

Operating Noise

35 / 29 dB in Eco Mode

Key: 895 cm Shift: 75 cm
Key: 388 cm Shift: 20 cm		Key: 388 cm Shift: 20 cm
	Key: 895 cm Shift: 75 cm

Weight

6,70 kg / 13,23 lbs.

Keystone

Vert.: +/-40°
Hori.: +/-20°

Illumination

Frequenz

H-sync: 15-99 kHz
V-sync: 50-120 Hz
Range max.: 162 MHz

Foot-Lamberts

124 fL / max. 551 cm screen width

425 cd/m²

Features

Full HD 1080P compatible

Lens shift Funktion

Integrated Mediaplayer

Freeze

Eco Mode

Kensington Slot

Password protection

PJLink™

Lan network compatible.

Screen Mirroring

In Comparison

The Epson EB G5150/NL compared to others not current "Standard-Portabel" projectors.

Ansi-Lumen:

Weight:

Contrast:

dB:

Black level:

Power cons.:

Picture Total Points:

Projector Total Points:

Popularity Top 100

Points:

Ranking:

81 (From: 7662)

Optional accessories
	Nackte Lampe	NLMP18411	111,02 €
	Lampe Ruby	Ruby-LMP18411	124,06 €
	Lampe Original	ELPLP47 / V13H010L47	EOL €
	Kompatible Lampe	LMP-K18411	73,72 €
	Luftfilter Kompatibel	Alternative zu:ELPAF17 / V13H134A17	24,69 €
	Objektiv Original	ELPLM06 / V12H004M06	2.541,40 €
	Objektiv Original	ELPLR03 / V12H004R03	EOL €
	Objektiv Original	ELPLM05 / V12H004M05	EOL €
	Objektiv Original	ELPLM04 / V12H004M04	EOL €
	Universal Fernbedienung	Fernb-uni-V3	22,31 €
	Fernbedienung Original	1485872	EOL €
	Luftfilter Original	ELPAF17 / V13H134A17	38,50 €
	Deckenhalterung 100-120	Halterung100	47,86 €

Standard-Lens

Optional Lenses

Name	Ratio	Distance	Shift V	Shift H	Zoom
Zoom Optional Lenses
ELPLM06	5.35-7.2:1	10.7-14.4 m	+/-50%	+/-10%	Manual
ELPLM05	3.57-5.41:1	7.1-10.8 m	+/-50%	+/-10%	Manual
ELPLM04	2.37-3.6:1	4.7-7.2 m	+/-50%	+/-10%
Fix Optional Lenses
ELPLR03	0.78:1	1.6 m	+/-50%	+/-10%	No Zoom

Status

2008 Discontinued (EOL) // Last update of the data: 2024-11-08

Data

Epson Website

User Manual english (13.21 MB)
Product Sheet
Product Sheet PowerLite USA
Product Sheet english HC

More Details


	https://www.projector-database.com/pro/epsonEBG5150-en.html

Due to our ongoing commitment to continuously improve the quality of our projector database, this brochure is also subject to change without notice. HCinema is not responsible for any errors or omissions contained in product descriptions.
