PDF/Print Version: Eiki LC HDT700 Projector

Brief Introduction

Beta 2.5

A brief introduction to the LC HDT700: The Eiki stationary LCD projector offers 7000 Ansi lumens, a contrast of 2700:1 and HDTV 1920 x 1080 resolution. The integrated lens shift gives you freedom when positioning the projector. 7000 Ansi lumens ensure that a picture width of 850 cm is also possible. The projector creates rooms with residual light with a smaller image width, we recommend a maximum of 567 cm. In the event that the image is still too small, the projector offers integrated edge blending software, which allows several projectors to project a large image together. Even 1080P video signals are no problem for the projector, and it even has the option of projecting HD 1080P Blu-rays onto the ceiling using 360Â° projection. The model built in 2011 is no longer offered by Eiki, but is still a popular projector in our database.

Display Type

3 x 1,2" LCD TFT Panel
HDTV 16/9 Liquid Crystal Display

Ansi-Lumen

Projector

7000 / 5400 im Eco Mode

Screen

3111 Lux (200 cm Screen width)

Contrast

2700:1 full on/off

Black Level

2,5926 min. Lumen

1,153 min. Lumen

Lens shift

Vert.: +66,67% -0% Hori.: +/-10%

Resolution

HDTV 1920 x 1080
2.073.600 Pixel

Video Modes

PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p

Application

Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very large screen width and rooms with plenty of light and shaded daylight.

Light Source

380W NSH Lamp
Article Nr.: 6103570464

Light Life

2000 h. 3000 h. in Eco Mode

Operating Costs

846 - 1170 cm


	Lux:	3111 Lux
	Room light max.:	622 Lux
	Candela pro m²:	990 cd/m²
	Foot-Lamberts:	289 fL

75 cm

Focus

Powered

Zoom

Powered 1,38

Objective

optional

Throw Ratio

4,23-5,85:1

Audio

Nein

Connections

HDMI 1.3b
DVI-D
D-sub 15 pin in und out
5 x BNC RGBHV in
S-Video in
Cinch Video in
RJ45 in
USB Typ B
RS232C

Ceiling Mounting

Yes, is possible.

Power

500 / 410W in Eco Mode

Size WxHxD

370 x 187 x 439 mm (14,6"x7,4"x17,3") 30,37 L/dm³

Operating Noise

38 dB in Eco Mode

Key: 488 cm Shift: 74 cm
Key: 488 cm Shift: 20 cm		Key: 488 cm Shift: 20 cm
	Key: 488 cm

Weight

11,60 kg / 25,57 lbs.

Keystone

Vert.: +/-30°
Hori.: +/-30°

Illumination

90%

Frequenz

H-sync: 15-120 kHz
V-sync: 48-100 Hz

Foot-Lamberts

289 fL / max. 850 cm screen width

990 cd/m²

Features

Full HD 1080P compatible

Direkt Power Off

Lens shift Funktion

Freeze

User logo

Eco Mode

Kensington Slot

360° installable

Edge Blending

Picture-in-Picture

Remote control with mouse control

Lan network compatible.

Crestron®-Software compatible.

Digital zoom

- and picture-beside-picture function

Inorganic LCD panels and QuaDrive® technology

Screen Mirroring

In Comparison

The Eiki LC HDT700 compared to others not current "Stationary" projectors.

Ansi-Lumen:

Weight:

Contrast:

dB:

Black level:

Power cons.:

Picture Total Points:

Projector Total Points:

Popularity Top 100

Points:

Ranking:

273 (From: 2514)

Optional accessories
	Lampe Ruby	Ruby-LMP20676	237,44 €
	Lampe Original	610-357-0464 / LMP149 / ET-SLMP149	EOL €
	Luftfilter Kompatibel	Alternative zu:POA-FIL-100 / 610 342 9571 / ET-SFYL100 / 003-003965-01	68,72 €
	Objektiv Original	ET-SW33 / LNS-W33	EOL €
	Universal Fernbedienung	Fernb-uni-V3	22,31 €
	Luftfilter Original	POA-FIL-100 / 610 342 9571 / ET-SFYL100 / 003-003965-01	EOL €
	Deckenhalterung 220	Halterung45	83,60 €

Standard-Lens

Optional Lenses

Name	Ratio	Distance	Shift V	Shift H	Zoom
Zoom Optional Lenses
LNS-W33	1.3-1.8:1	2.6-3.6 m	50%	+/-10%	Powered
AH-24251	5.58-8.83:1	11.2-17.7 m	66.67%	+/-10%	Powered
AH-24241	4.23-5.85:1	8.5-11.7 m	66.67%	+/-10%	Powered
AH-23133	2.39-4.21:1	4.8-8.4 m	50%	+/-10%	Powered
AH-23123	1.29-1.81:1	2.6-3.6 m	50%	+/-10%	Powered
AH-23123	1.82-2.36:1	3.6-4.7 m	50%	+/-10%	Powered
Fix Optional Lenses
AH-32013	0.84:1	1.7 m	0.0% Fix		No Zoom

Status

2011 Discontinued (EOL) // Last update of the data: 2025-03-03

Data

Eiki Contact

User Manual english (19.67 MB)
Product Sheet english
Product Sheet english
Product Sheet english HC

More Details


	https://www.projector-database.com/pro/eikilchdt700-en.html

Due to our ongoing commitment to continuously improve the quality of our projector database, this brochure is also subject to change without notice. HCinema is not responsible for any errors or omissions contained in product descriptions.
