Barco HDF W26
Brief Introduction
Beta 2.5
 The Barco model HDF W26 is a DLP projector with WUXGA 1920 x 1200 resolution and a contrast of 2600:1. The built-in lens shift function provides freedom when setting up. The projector will be able to illuminate an image width of 1541 cm well. Rooms with residual light can be created by the projector with a smaller image width, max. 1027 cm is recommended here. In the event that the image is still too small, the projector offers integrated edge blending software, with which several projectors can project a large image together. On the market since 2012, the model is no longer offered by the manufacturer Barco.
Display Type 3 x 0,96" DLP Chip
WUXGA 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
 23000 / 26000 Center lumens
Screen
 10222 Lux (200 cm Screen width)
Contrast 2600:1 full on/off 2600:1 full on/off
Black Level 8,8462 min. Lumen 3,935 min. Lumen
Offset -
Resolution WUXGA 1920 x 1200
2.304.000 Pixel
Video Modes PAL, SECAM, NTSC, HDTV 720p, 1080i, EDTV 480p, 576p
Application Event | Very large screen width and rooms with plenty of light and shaded daylight.
Light Source 3.8KW Xenon Lamp
Article Nr.: R9854537 / R9854420
Light Life 750 h.
Operating Costs -
240 cm (no Zoom)



Lux: 10222 Lux
Room light max.: 2044 Lux
Candela pro m²: 3255 cd/m²
Foot-Lamberts: 950 fL


16/9 screen width:200 cm
            Screen: 1 Gain
Focus Manual
Zoom No Zoom
Objective optional
Throw Ratio 1,2:1
Audio Nein
Connections DVI mit HDCP
3G HDSDI/SDI
weitere optional
Ceiling Mounting Yes, is possible.
Power 4550W
Size WxHxD 707 x 548 x 1025 mm (27,8"x21,6"x40,4") 397,12 L/dm³
Operating Noise 60dB

Weight 99,00 kg / 218,26 lbs.
Keystone -
Illumination 90%
Frequenz Range max.: 200 MHz
Foot-Lamberts 950 fL / max. 1541 cm screen width
3255 cd/m²
Features Warping
Edge Blending
Picture-in-Picture
Control via web browser
Lan network compatible.
Screen Mirroring -
In Comparison
The Barco HDF W26 compared to others not current "Event" projectors.
Ansi-Lumen:
18 Weight:
60
Contrast:
1 dB:
21
Black level:
85 Power cons.:
47
Picture Total Points:35 Projector Total Points:43
Popularity Top 100
39 popularity points 46 popularity points 39 popularity points 57 popularity points 59 popularity points 53 popularity points
Points:
53
Ranking: 51 (From: 576)
Optional accessories
(PXL-30BA2) Nackte Lampe OriginalR9863005EOL €
Wiederaufbereitet Lampe OriginalR9854538 / R9854536 / R9854541EOL €
(PXL-40BA) Nackte Lampe OriginalR9801374EOL €
Lampe OriginalR9854537 / R9854535 / R9854540EOL €
Standard-Lens Optional Lenses
NameRatioDistanceShift V Shift HZoom
Zoom Optional Lenses
TLD (7.5 ~ 11.5:1) 7.5-11.5:115-23 m 55-5% +/-15% Powered
TLD (4.5 ~ 7.5:1) 4.5-7.5:19-15 m 55-5% +/-15% Powered
TLD (2.8 ~ 4.5:1) 2.8-4.5:15.6-9 m 55-5% +/-15% Powered
TLD (2.0 ~ 2.8:1) 2-2.8:14-5.6 m 55-5% +/-15% Powered
TLD (1.5 ~ 2.0:1) 1.5-2:13-4 m 55-5% +/-15% Powered
Fix Optional Lenses
TLD (1.2:1) 1.2:1 2.4 m No Zoom
TLD (0.73:1) 0.73:1 1.5 m No Zoom
Status 2012 Discontinued (EOL) // Last update of the data: 2025-03-03
