Categorized in the Game-Portabel segment, the HY300 projector from ANMESC projects with a HDTV 1280 x 720 resolution, alongside 120 ANSI lumens and a contrast of 1500:1. The manufacturer specifies a durability of 30000 hours for the LED light source – calculating to 20.5 years at four hours of use per day. For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups. Regarding projection size, the value of 120 ANSI lumens allows for an image width of up to 111 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 74 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P and 4K. Also on board is a local media player that allows reading and playing content directly from storage media. For wireless audio output, the projector also supports Bluetooth, making it easy to quickly connect external soundbars. Since the projector supports Miracast and Airplay screen mirroring, video signals can also be streamed wirelessly from the end device. In the specifications, the operating noise is listed at a mere 25 decibels, indicating very quiet cooling.
Display Type
1 x LCD TFT Panel HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
120
Screen
53 Lux (200 cm Screen width)
Contrast
1500:1 full on/off
1500:1 full on/off
Black Level
0,0800 min. Lumen
0,035 min. Lumen
Offset
-
Resolution
HDTV 1280 x 720
921.600 Pixel UHD (4K2K) 3840 x 2160 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p Media player formats: Mediaplayer
Application
Game-Portabel | Very portable, small-screen projections. Very narrow picture width and rooms with very little light.
Light Source
LED
Light Life
30000 h.
Operating Costs
0,00 € LED
The projection is too dark. The screen width should be reduced.
Lux:
53 Lux
Contrast:
1500:1
Candela pro m²:
17 cd/m²
Foot-Lamberts:
5 fL
•
Focus
Automatic
Zoom
No Zoom
Objective
-
Throw Ratio
-
Audio
Built-in loudspeaker
Connections
HDMI in
USB in
Audio Mini Jack in und out
Bluetooth 5.0
Full HD 1080P compatible
