The DP03 is a LCD projector by YOWHICK, whose specifications list 350 ANSI lumens, a contrast of 1000:1 and a HDTV 1920 x 1080 resolution. An LED lifespan of 80000 hours is noted in the data sheet for this model – equivalent to a usable life of 54.8 years at 4 hours a day. The image geometry can be adjusted via the built-in keystone correction so that a clean, rectangular display is achieved even with non-ideal placement. To allow for cross-manufacturer brightness comparisons, the stated ANSI lumen value is based on a conversion of the lumen specifications. A look at the light output reveals: The 350 ANSI lumens are sufficient to illuminate an image width of up to 321 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 214 cm. Regarding signal processing, the model is compatible with incoming 1080P content and 4K. As an additional feature, an integrated media player enables the direct playback of files without an external source device. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Since the projector supports Miracast and Airplay screen mirroring, video signals can also be streamed wirelessly from the end device. In the specifications, the operating noise is listed at a mere 25 decibels, indicating very quiet cooling.
Display Type
1 x LCD TFT Panel HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
350
Screen
156 Lux (200 cm Screen width)
Contrast
1000:1 full on/off
1000:1 full on/off
Black Level
0,0500 min. Lumen
0,156 min. Lumen
Offset
-
Resolution
HDTV 1920 x 1080
2.073.600 Pixel UHD (4K2K) 3840 x 2160 compressed
Video Modes
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p Media player formats: PPT, EXCEL, PDF, WORD
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Very narrow picture width and rooms with very little light.
Light Source
LED
Light Life
80000 h.
Operating Costs
0,00 € LED
The projection is okay. A smaller screen width would result in a brighter image.
Lux:
156 Lux
Contrast:
1000:1
Candela pro m²:
48 cd/m²
Foot-Lamberts:
14 fL
•
Focus
Manual
Zoom
No Zoom
Objective
-
Throw Ratio
-
Audio
2 x 5W
Connections
HDMI in
2x USB-A in
D-Sub 15 Pin in
AV in
TF Card
Audio Mini Jack out
Bluetooth 5.3
Full HD 1080P compatible
