According to Viewsonic, the PJD6350 model provides 3200 ANSI lumens, a contrast ratio of 15000:1 alongside a XGA 1024 x 768 resolution. The runtime of the lamp in this model is estimated at 5000 hours before a replacement is necessary. With two hours of daily operation, this corresponds to a period of 6.8 years. The image geometry can be adjusted via the built-in keystone correction so that a clean, rectangular display is achieved even with non-ideal placement. A look at the light output reveals: The 3200 ANSI lumens are sufficient to illuminate an image width of up to 493 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 329 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P as well as 3D. The built-in HDMI-MHL (Mobile High-Definition Link) port enables screen mirroring from a smartphone while simultaneously charging it. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. This model dates back to 2015 and is no longer part of Viewsonic's current product range.
Display Type
1 x 0,55" DLP Chip XGA 4/3 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3200
Screen
1067 Lux (200 cm Screen width)
Contrast
15000:1 full on/off
15000:1 full on/off
Black Level
0,2133 min. Lumen
0,071 min. Lumen
Offset
50% Exactly on screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel UXGA 1600 x 1200 compressed
Frame-Packing (Full HD 3D) | Frame Sequential (3D Ready) |
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Real Full HD 3D
