Brief Introduction
Beta 2.5 |
The standard portable Megapower ML-635 (PD-X713) DLP projector has 3500 Ansi lumens, a contrast of 2000:1 and an XGA 1024 x 768 resolution. An image width of up to 515 cm is possible as the projector has 3500 Ansi lumens. The projector can create rooms with residual light with a smaller image width, we recommend a maximum of 343 cm. It came onto the market in 2007 and is no longer offered by the manufacturer Megapower.
|
| Display Type |
1 x 0,7" DDR DLP Chip
XGA 4/3 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
3500 |
Screen |
1167 Lux (200 cm Screen width) |
| Contrast |
2000:1 full on/off |
2000:1 full on/off
|
| Black Level |
1,7500 min. Lumen |
0,584 min. Lumen |
| Offset |
-
|
| Resolution |
XGA 1024 x 768
786.432 Pixel |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with a little more ambient light, max. 200 lumens. |
| Light Source |
300W Lamp
Article Nr.: ML635LM
|
|
| Light Life |
1700 h. |
| Operating Costs |
-
|
|
|
 |
|
Lux: |
1167 Lux |
|
Room light max.: |
233 Lux |
|
Candela pro m²: |
370 cd/m² |
|
Foot-Lamberts: |
108 fL |
|
 |
|
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,2 |
| Objective |
- |
| Throw Ratio |
- |
| Audio |
1 x 2W |
| Connections |
DVI-D
D-sub 15pin in und out
S-Video in
Cinch video in
Mini Jack Audio in
USB in
RS232C |
| Ceiling Mounting |
Yes, is possible. |
| Power |
350W |
| Size WxHxD |
309 x 102 x 229 mm (12,2"x4"x9") 7,22 L/dm³
|
| Operating Noise |
35 / 32 dB in Eco Mode |
|
| Weight |
3,20 kg / 7,05 lbs. |
| Keystone |
Vert.: +/-15°
|
| Illumination |
80% |
| Frequenz |
- |
| Foot-Lamberts |
108 fL
/ max. 515 cm screen width |
| Candela m² |
370 cd/m² |
| Features |
 Eco Mode
4-segment RGBW colour wheel
|
|
- |
In Comparison
The Megapower ML-635 (PD-X713) compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
42 |
Weight: |
|
85 |
| Contrast: |
|
1 |
dB: |
|
36 |
| Black level: |
|
93 |
Power cons.: |
|
96 |
| Picture Total Points: | 45 |
Projector Total Points: | 72 |
|
| Popularity Top 100 |
|
| Points: |
|
3 |
| Ranking: |
7426 (From: 7662) |
|
|
|
|
|
| Status |
2007 Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet english
Product Sheet english HC
|
Megapower Website
