The Geha compact 009 is a LED-DLP projector offering 1000 ANSI lumens, a contrast of 2000:1 and a resolution of XGA 1024 x 768. The manufacturer lists the lamp life at 2000 hours. Should a perpendicular setup to the screen not be possible, the integrated keystone correction (horizontal and vertical) helps to realign the image into a perfect rectangle. A look at the light output reveals: The 1000 ANSI lumens are sufficient to illuminate an image width of up to 275 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 183 cm. The model is currently no longer actively offered on the market by the manufacturer.
Display Type
1 x 0,7" 12° DDR DLP Chip XGA 4/3 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
1000
Screen
333 Lux (200 cm Screen width)
Contrast
2000:1 full on/off
2000:1 full on/off
Black Level
0,5000 min. Lumen
0,167 min. Lumen
Offset
60% 15 cm over screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel UXGA 1600×1200 compressed
Video Modes
Pal, Secam, NTSC, HDTV 480p
Application
Micro-Portabel | Small mobile presentations. Small screen width, rooms with very little ambient light below 50 lumens.
